Pamameters
| Model | Dimension | Power |
|---|---|---|
| DTS-737A | 66*45*13 | 1.6kw |
| Voltage | N.W. | G.W |
| 380V/50Hz | 950KG | 1100KG |
| AIR PRESSURE | DIMENSION | |
| 0.4-0.5MP | 98*175*195CM |
Features
- The machine is operated using an oil pressure operated system.
- The claw adopts a quick release design, which is easy to replace and is fixed to the patented double track claw disc mechanism (Patent No. 36247).
- The left and right last claws can be set with automatic rotation action (Patent No. 86206459), which makes the collar effect at the inner waist turning best.
- Each group of left and right paws can set the automatic pull-down stroke or manually operate the lifting to balance the tension of the vamp, so as to correct the best position of the upper bonding.
- The lifting height of the inner support is adjusted by the outside of the machine platform.
- The lifting of the inner support platform can be set as a two-stage action, which can prevent the last from sliding with the action of the heel top seat.
- The sweeping mechanism moves forward, and the speed can be adjusted continuously
